| DF-XXW-XXXWF |
|
| 10W~22W LED Tube Type |
|
Features
- Restrofit for fluorescent lamp 32W/40W
- Wide beam angle (150~200 deg)
- Converter use (Options: internat/external converter type)
- Semi-permanent life time (50,000Hrs.)
- Low power consumption 40% required: compared to normal fluorescent lamp
- Environmental friendly product (Pb/Hg/Cd free)
- Emitting heat temperature: 45
℃
- Low Ultraviolet/electromagnetic wave out
- No Dazzling
Specifications
|
|
Unit
|
Basic Model
|
|
DF-10W058WF
|
DF-12W058WF
|
DF-18W120WF
|
DF-20W120WF
|
DF-22W120WF
|
|
Power Consumption
|
W
|
10
|
12
|
18
|
20
|
22
|
|
Input Voltage
|
V
|
AC 100V ~ 245V, 50/60Hz
|
|
Power Factor
|
|
>0.90
|
|
Luminance
|
lux/1m
|
180
|
220
|
370
|
420
|
450
|
|
Luminous Flux
|
lm
|
800
|
950
|
1,350
|
1,500
|
1,650
|
|
Luminescent Efficiency
|
lm/W
|
> 65
|
|
Color Temp.
|
Kelvin
|
3,000K / 5,000K / 6,500K
|
|
Color Rendering
|
|
>70
|
|
View Angle
|
deg
|
>150 deg
|
|
Diameter
|
mm
|
Φ16(T5) / Φ25(T8) / Φ29(T10) / Φ32(T12)
|
|
Length
|
mm
|
580
|
580
|
1198
|
1198
|
1198
|
|
Base Type
|
|
G13
|
|
Weight
|
g
|
160
|
160
|
340
|
340
|
340
|
|
Operating Temp.
|
℃
|
-20 ~ 45℃
|
|
Storage Temp.
|
℃
|
-40 ~ 85℃
|
|
Life Time
|
Hrs
|
30,000 ~ 50,000 Hrs.
|
|
|
